Input Voltage 230 – 460 VAC 1 ph, 3 ph +/- 10% 50/60 Hz
Input Current Draw 10 A, 400 – 460 V / 11 A, 380 V / 20 A, 230 V
Welding Output, TIG (GTAW)
300 A / 20 V @ 40% Duty Cycle 3 ph
250 A / 20 V @ 60% Duty Cycle 3 ph
200 A / 18 V @ 100% Duty Cycle 1/3 ph
Welding Output, Stick (SMAW)
300 A / 30 V @ 40% Duty Cycle 3ph
250 A / 30 V @ 60% Duty Cycle 3ph
200 A / 28 V @ 100% Duty Cycle 1/3ph
Current Range 5-200 A, 1 ph
5-300 A, 3 ph
Efficiency at Max Current 85% TIG
89% Stick
Maximum Output 300 A
Power Factor at Max Current 0.96
Fuse Slow 16 A at 400 V
Energy Save Mode 91 W
Open Circuit Voltage 32 V with VRD
48 V without VRD
Rated kVA 11.3 kVA
Supply Plug CEE 16 A
Input Cable 10 ft. (3 m)
Approvals CE, CSA
Protection Class IP23
Dimensions, L x W x H 18.1 x 7.9 x 12.6 in. (460 x 200 x 320 mm)
Weight 37.3 lbs. (16.9 kg) without cooler
59.3 lbs. (59.3 kg) with cooler
